First Step in Performance Analysis: Understanding Thread Sequencing

When analyzing the performance of Flutter applications, developers need to capture application traces using profiling tools and analyze these traces. Flutter's rendering process relies on several critical threads. This guide introduces these essential threads and their sequence in the rendering workflow.

Analysis Tools

Commonly used tools include:

Recommended Tool: DevEco Studio Profiler

For usage instructions, see:

DevEco Profiler Tool Introduction

Thread Sequence

After mastering the profiling tools, you can capture traces of Flutter applications. Traces contain all threads during application runtime. For effective analysis, bookmark and arrange threads in the following order:

Bookmarked Threads Explained

VSyncGenerator

Software Vsync signal generator that provides frame synchronization capabilities.
DVSync-app

Delivers software Vsync signals to the application.
mmi_service

Handles multimodal input events triggered by touchscreen interactions.
Main Application Thread

The primary thread matching the application process ID and name.

Hosts platform-level operations and plugin code execution.
flutter'PointerEvent'

Thread transferring touch events from the main thread to the UI thread for processing.

(May not always appear in traces).
1.ui (UI Thread)

Executes Dart code in the Dart VM.
- Processes developer code and framework-generated logic
- Builds the layer tree (device-independent rendering commands)
- Transfers layer tree to the raster thread Critical: Never block this thread! Appears at the bottom of performance layers.
1.raster (Raster Thread)

Processes the layer tree and communicates with the GPU.
- Executes Skia graphics library operations
- Performs rasterization for the GPU (runs on CPU)
- Appears at the top of performance layers. Note: Slowdowns indicate issues in Dart code logic.
DVSync-rs

Provides software Vsync signals to the Render Service (RS) process.
render_service

Main thread of the RS process (first stage of display processing).
RSUniRenderThread

RS process thread (second stage of display processing).
RSHardwareThread

RS process thread (third stage of display processing).
dpu_gfx_primary

Hardware DPU (Display Processing Unit) signal thread.
