Amazon EKS (Auto Mode) Infrastructure as Code with Terraform

Introduction:
Click here: https://dev.to/aws-builders/enable-eks-auto-mode-on-an-existing-cluster-1j5m

Terraform Implementation of Amazon EKS Auto Mode

locals {
  cluster_name = "my-vpc-eks-test"
}

module "vpc_eks" {
  source  = "terraform-aws-modules/vpc/aws"
  version = "5.18.1"

  name = "my-vpc-eks-test"

  cidr                  = "10.20.0.0/19"

  azs             = ["eu-west-2a", "eu-west-2b", "eu-west-2c"]
  private_subnets = ["10.20.0.0/21", "10.20.8.0/21", "10.20.16.0/21"]
  public_subnets  = ["10.20.24.0/23", "10.20.26.0/23", "10.20.28.0/23"]

  enable_nat_gateway     = true
  single_nat_gateway     = true
  one_nat_gateway_per_az = false

  enable_vpn_gateway = true

  enable_dns_hostnames = true
  enable_dns_support   = true

  propagate_private_route_tables_vgw = true
  propagate_public_route_tables_vgw  = true

  private_subnet_tags = {
    "kubernetes.io/role/internal-elb" = "1",
    "mapPublicIpOnLaunch"             = "FALSE"
    "karpenter.sh/discovery"          = local.cluster_name
    "kubernetes.io/role/cni"          = "1"
  }

  public_subnet_tags = {
    "kubernetes.io/role/elb" = "1",
    "mapPublicIpOnLaunch"    = "TRUE"
  }

  tags = {
    "kubernetes.io/cluster/${local.cluster_name}" = "shared"
  }
}

resource "aws_eks_cluster" "cluster" {
  name     = local.cluster_name
  role_arn = aws_iam_role.cluster.arn
  version  = "1.32"

  vpc_config {
    subnet_ids              = module.vpc_eks.private_subnets
    security_group_ids      = []
    endpoint_private_access = "true"
    endpoint_public_access  = "true"
  }

  access_config {
    authentication_mode                         = "API"
    bootstrap_cluster_creator_admin_permissions = false
  }

  bootstrap_self_managed_addons = false

  zonal_shift_config {
    enabled = true
  }

  compute_config {
    enabled       = true
    node_pools    = ["general-purpose", "system"]
    node_role_arn = aws_iam_role.node.arn
  }

  kubernetes_network_config {
    elastic_load_balancing {
      enabled = true
    }
  }

  storage_config {
    block_storage {
      enabled = true
    }
  }
}

resource "aws_iam_role" "cluster" {
  name = "eks-test-cluster-role"

  assume_role_policy = data.aws_iam_policy_document.cluster_role_assume_role_policy.json
}

resource "aws_iam_role_policy_attachments_exclusive" "cluster" {
  role_name = aws_iam_role.cluster.name
  policy_arns = [
    "arn:aws:iam::aws:policy/AmazonEKSClusterPolicy",
    "arn:aws:iam::aws:policy/AmazonEKSComputePolicy",
    "arn:aws:iam::aws:policy/AmazonEKSBlockStoragePolicy",
    "arn:aws:iam::aws:policy/AmazonEKSLoadBalancingPolicy",
    "arn:aws:iam::aws:policy/AmazonEKSNetworkingPolicy",
    "arn:aws:iam::aws:policy/AmazonEKSServicePolicy",
    "arn:aws:iam::aws:policy/AmazonEKSVPCResourceController"
  ]
}

data "aws_iam_policy_document" "cluster_role_assume_role_policy" {
  statement {
    actions = ["sts:AssumeRole", "sts:TagSession"]

    principals {
      type        = "Service"
      identifiers = ["eks.amazonaws.com"]
    }
  }
}

resource "aws_iam_role" "node" {
  name = "eks-auto-node-example"
  assume_role_policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Action = ["sts:AssumeRole"]
        Effect = "Allow"
        Principal = {
          Service = "ec2.amazonaws.com"
        }
      },
    ]
  })
}

resource "aws_iam_role_policy_attachment" "node_AmazonEKSWorkerNodeMinimalPolicy" {
  policy_arn = "arn:aws:iam::aws:policy/AmazonEKSWorkerNodeMinimalPolicy"
  role       = aws_iam_role.node.name
}

resource "aws_iam_role_policy_attachment" "node_AmazonEC2ContainerRegistryPullOnly" {
  policy_arn = "arn:aws:iam::aws:policy/AmazonEC2ContainerRegistryPullOnly"
  role       = aws_iam_role.node.name
}

Ref: https://github.com/terraform-aws-modules/terraform-aws-eks/blob/v20.36.0/examples/eks-auto-mode/main.tf
