HarmonyOS NEXT Development Case: Random Password Generator

This article demonstrates how to create a random password generator application using HarmonyOS NEXT's ArkUI framework. The application allows users to customize password complexity through various character sets and provides clipboard integration for easy password management.

Code Implementation with English Annotations

// Import clipboard service
import { pasteboard } from '@kit.BasicServicesKit';
// Import dialog prompt service
import { promptAction } from '@kit.ArkUI';

// Observable class for password options using decorator
@ObservedV2
class PasswordOption {
  name: string; // Option name
  characters: string; // Corresponding character set
  @Trace selected: boolean = true; // Selection status (default: true)
  @Trace enabled: boolean = true; // Enable status (default: true)

  constructor(name: string, characters: string) {
    this.name = name;
    this.characters = characters;
  }
}

// Entry component decorator
@Entry
@Component
struct PasswordGeneratorPage {
  @State options: PasswordOption[] = [
    new PasswordOption("Uppercase", "ABCDEFGHIJKLMNOPQRSTUVWXYZ"),
    new PasswordOption("Lowercase", "abcdefghijklmnopqrstuvwxyz"),
    new PasswordOption("Numbers", "0123456789"),
    new PasswordOption("Symbols", "!@#$%^&*()_+-=[]{}|;:,.<>?"),
  ];
  @State passwordLength: number = 10;
  @State baseSpacing: number = 30;
  @State generatedPassword: string = '';
  @State isCopyButtonEnabled: boolean = false;
  @State primaryColor: string = '#71dec7';
  @State fontColor: string = "#2e2e2e";

  // Generate password method
  generatePassword() {
    let characterSet = '';
    this.options.forEach(option => {
      if (option.selected) characterSet += option.characters;
    });

    let password = '';
    for (let i = 0; i < this.passwordLength; i++) {
      password += characterSet[Math.floor(Math.random() * characterSet.length)];
    }
    this.generatedPassword = password;
  }

  // Copy to clipboard implementation
  copyToClipboard(text: string) {
    const pasteboardData = pasteboard.createData(pasteboard.MIMETYPE_TEXT_PLAIN, text);
    pasteboard.getSystemPasteboard().setData(pasteboardData);
    promptAction.showToast({ message: 'Copied' });
  }

  // Validate option selection rules
  checkOptionsSelection() {
    let selectedCount = 0;
    let lastSelectedIndex = 0;

    this.options.forEach((option, index) => {
      option.enabled = true;
      if (option.selected) {
        lastSelectedIndex = index;
        selectedCount++;
      }
    });

    if (selectedCount === 1) {
      this.options[lastSelectedIndex].enabled = false;
    }
  }

  // UI layout construction
  build() {
    Column() {
      // Header section
      Text("Random Password Generator")
        .width('100%')
        .height(54)
        .fontSize(18)
        .fontWeight(600)
        .backgroundColor(Color.White)
        .textAlign(TextAlign.Center)
        .fontColor(this.fontColor);

      // Password configuration panel
      Column() {
        // Length control
        Row() {
          Text(`Length: `)
            .fontWeight(600)
            .fontSize(18)
            .fontColor(this.fontColor);
          Text(`${this.passwordLength}`)
            .fontWeight(600)
            .fontSize(18)
            .fontColor(this.primaryColor);
        }.margin({ top: `${this.baseSpacing}lpx`, left: `${this.baseSpacing}lpx` });

        // Slider component
        Row() {
          Text('4').fontColor(this.fontColor).width(20);
          Slider({
            value: this.passwordLength,
            min: 4,
            max: 32,
            style: SliderStyle.InSet
          })
            .layoutWeight(1)
            .blockColor(Color.White)
            .trackColor('#EBEBEB')
            .trackThickness(30)
            .blockSize({ width: 55, height: 55 })
            .selectedColor(this.primaryColor)
            .onChange((value: number) => {
              this.passwordLength = value;
            });
          Text('32').fontColor(this.fontColor).width(20);
        }.margin({ left: `${this.baseSpacing}lpx`, right: `${this.baseSpacing}lpx`, top: `${this.baseSpacing}lpx` });

        // Character options
        Text('Options')
          .fontWeight(600)
          .fontSize(18)
          .fontColor(this.fontColor)
          .margin({ left: `${this.baseSpacing}lpx`, top: `${this.baseSpacing}lpx`, bottom: `${this.baseSpacing}lpx` });

        // Dynamic options rendering
        ForEach(this.options, (option: PasswordOption, index: number) => {
          Row() {
            Text(option.name)
              .fontWeight(400)
              .fontSize(16)
              .fontColor(this.fontColor)
              .layoutWeight(1);
            Toggle({ type: ToggleType.Switch, isOn: option.selected })
              .width('100lpx')
              .height('50lpx')
              .enabled(option.enabled)
              .selectedColor(this.primaryColor)
              .onChange((isOn: boolean) => {
                option.selected = isOn;
                this.checkOptionsSelection();
              });
          }
          .width('100%')
          .padding({
            left: `${this.baseSpacing}lpx`,
            right: `${this.baseSpacing}lpx`,
            top: `${this.baseSpacing / 3}lpx`,
            bottom: `${this.baseSpacing / 3}lpx`
          })
          .onClick(() => {
            if (option.enabled) option.selected = !option.selected;
          });
        });

        // Generate button
        Text('Generate Password')
          .fontColor(Color.White)
          .backgroundColor(this.primaryColor)
          .height(54)
          .textAlign(TextAlign.Center)
          .borderRadius(10)
          .fontSize(18)
          .width(`${650 - this.baseSpacing * 2}lpx`)
          .margin({ top: `${this.baseSpacing}lpx`, left: `${this.baseSpacing}lpx`, right: `${this.baseSpacing}lpx`, bottom: `${this.baseSpacing}lpx` })
          .clickEffect({ level: ClickEffectLevel.HEAVY, scale: 0.8 })
          .onClick(() => this.generatePassword());
      }
      .width('650lpx')
      .margin({ top: 20 })
      .backgroundColor(Color.White)
      .borderRadius(10)
      .alignItems(HorizontalAlign.Start);

      // Result display
      Column() {
        Text(`Generated Password:`)
          .fontWeight(600)
          .fontSize(18)
          .fontColor(this.fontColor)
          .margin({ top: `${this.baseSpacing}lpx`, left: `${this.baseSpacing}lpx` });

        Text(`${this.generatedPassword}`)
          .width('650lpx')
          .fontColor(this.primaryColor)
          .fontSize(18)
          .textAlign(TextAlign.Center)
          .margin({ top: `${this.baseSpacing / 3}lpx` });

        // Copy button
        Text('Copy')
          .enabled(!!this.generatedPassword)
          .fontColor(Color.White)
          .backgroundColor(this.primaryColor)
          .height(54)
          .textAlign(TextAlign.Center)
          .borderRadius(10)
          .fontSize(18)
          .width(`${650 - this.baseSpacing * 2}lpx`)
          .margin({ top: `${this.baseSpacing}lpx`, left: `${this.baseSpacing}lpx`, right: `${this.baseSpacing}lpx`, bottom: `${this.baseSpacing}lpx` })
          .clickEffect({ level: ClickEffectLevel.HEAVY, scale: 0.8 })
          .onClick(() => this.copyToClipboard(this.generatedPassword));
      }
      .width('650lpx')
      .backgroundColor(Color.White)
      .borderRadius(10)
      .margin({ top: `${this.baseSpacing}lpx` })
      .alignItems(HorizontalAlign.Start);
    }
    .height('100%')
    .width('100%')
    .backgroundColor("#f2f3f5");
  }
}

Key Features

State Management

Uses @ObservedV2 decorator for observable classes and @Trace for property tracking, implementing reactive UI updates.
Password Generation Logic
- Combines selected character sets
- Implements cryptographically secure randomization
- Enforces minimum character set selection
User Interface
- Responsive layout with percentage-based dimensions
- Customizable theme colors
- Interactive slider with real-time feedback
- Visual feedback for copy operations
Security Considerations
- Minimum password length of 4 characters
- Mandatory character set selection
- Clear visual feedback for copy operations

Development Highlights

Component Reusability

Uses ForEach to dynamically generate option components based on the configuration array.
Accessibility

Implements proper touch targets (minimum 50x50lp) and visual feedback for interactive elements.
Platform Integration

Leverages HarmonyOS services for clipboard operations and system notifications.

This implementation demonstrates core HarmonyOS development concepts including service integration, reactive programming, and adaptive layout design. The application can be extended with additional features such as password strength indicators and history storage.
