Introduction

The Strategy Design Pattern is a behavioral design pattern that enables selecting an algorithm's behavior at runtime. Rather than implementing a single algorithm directly, code receives run-time instructions as to which algorithm to use.

Think of it like choosing different routes to get to work: walking, driving, or taking public transport. Each "strategy" achieves the same goal (getting to work) but uses a different approach. Instead of hardcoding your commute method, you can switch between strategies based on weather, time constraints, or other factors.

Pattern Classification

Type: Behavioral
Scope: Object

Problem Statement

Software often needs to support multiple ways of performing the same task. Without a proper pattern, this leads to:

Conditional logic (if/else or switch statements) scattered throughout the code
Difficulty adding new algorithms without modifying existing code
Code that violates the Open/Closed Principle
Tight coupling between the client code and the specific algorithms
Challenges in unit testing individual algorithms separately

For example, consider a payment processing system that must support multiple payment methods. Traditional approaches might use complex conditional branches that become increasingly difficult to maintain as more payment options are added.

Anti-Pattern Case Study

Here's an example of code that doesn't use the Strategy pattern but should:

public class ShippingCalculator
{
    public decimal CalculateShipping(Order order, string shippingMethod)
    {
        decimal shippingCost = 0;

        switch (shippingMethod)
        {
            case "Standard":
                // Standard shipping calculation
                shippingCost = order.Weight * 1.5m;
                if (order.Weight > 10)
                {
                    shippingCost *= 0.9m; // 10% discount for heavy items
                }
                break;

            case "Express":
                // Express shipping calculation
                shippingCost = order.Weight * 3.0m;
                if (order.TotalAmount > 100)
                {
                    shippingCost -= 5; // $5 off for orders over $100
                }
                break;

            case "NextDay":
                // Next day shipping calculation
                shippingCost = order.Weight * 4.5m;
                if (order.Distance > 100)
                {
                    shippingCost += 10; // $10 surcharge for long distances
                }
                break;

            default:
                throw new ArgumentException("Unsupported shipping method");
        }

        return shippingCost;
    }
}

// Supporting class for the example
public class Order
{
    public decimal Weight { get; set; }
    public decimal TotalAmount { get; set; }
    public int Distance { get; set; }
}

This implementation has several problems:

Adding a new shipping method requires modifying existing code
The class violates the Single Responsibility Principle by handling multiple algorithms
If the calculation logic needs to be reused elsewhere, it cannot be easily extracted
As more shipping methods are added, the switch statement grows unwieldy

Over time, these issues compound. When business requirements change (e.g., adding regional shipping rules or promotional discounts), the code becomes increasingly complex and error-prone. Refactoring might require changes throughout the application, leading to potential regressions.

Solution

The Strategy pattern addresses these issues by:

Defining a family of algorithms (strategies)
Encapsulating each algorithm in separate classes
Making the algorithms interchangeable within that family

The pattern consists of:

Strategy Interface: Defines the common interface for all concrete strategies
Concrete Strategies: Implement the algorithm using the strategy interface
Context: Maintains a reference to a strategy object and delegates to it

Implementation in `C#`

// Step 1: Define the strategy interface
public interface IShippingStrategy
{
    decimal CalculateShipping(Order order);
}

// Step 2: Implement concrete strategies
public class StandardShippingStrategy : IShippingStrategy
{
    public decimal CalculateShipping(Order order)
    {
        decimal cost = order.Weight * 1.5m;
        if (order.Weight > 10)
            cost *= 0.9m; // 10% discount for heavy items
        return cost;
    }
}

public class ExpressShippingStrategy : IShippingStrategy
{
    public decimal CalculateShipping(Order order)
    {
        decimal cost = order.Weight * 3.0m;
        if (order.TotalAmount > 100)
            cost -= 5; // $5 off for orders over $100
        return cost;
    }
}

public class NextDayShippingStrategy : IShippingStrategy
{
    public decimal CalculateShipping(Order order)
    {
        decimal cost = order.Weight * 4.5m;
        if (order.Distance > 100)
            cost += 10; // $10 surcharge for long distances
        return cost;
    }
}

// Step 3: Create the context class
public class ShippingCalculator
{
    private IShippingStrategy _strategy;

    public ShippingCalculator(IShippingStrategy strategy)
    {
        _strategy = strategy;
    }

    public void SetStrategy(IShippingStrategy strategy)
    {
        _strategy = strategy;
    }

    public decimal CalculateShipping(Order order)
    {
        return _strategy.CalculateShipping(order);
    }
}

Step-by-Step Breakdown

We define the IShippingStrategy interface with a single method CalculateShipping that takes an order and returns the shipping cost.
We implement three concrete strategies (StandardShippingStrategy, ExpressShippingStrategy, and NextDayShippingStrategy), each with its own algorithm for calculating shipping costs.
We create a ShippingCalculator context class that:
- Takes a strategy in its constructor
- Provides a method to change the strategy at runtime
- Delegates the actual calculation to the current strategy
This approach separates the calculation algorithms from the context that uses them, making the system much more flexible and maintainable.

Usage Examples

// Create an order
var order = new Order
{
    Weight = 15,
    TotalAmount = 150,
    Distance = 120
};

var standardShipping = new StandardShippingStrategy();
var expressShipping = new ExpressShippingStrategy();
var nextDayShipping = new NextDayShippingStrategy();

var calculator = new ShippingCalculator(standardShipping);

decimal standardCost = calculator.CalculateShipping(order);
Console.WriteLine($"Standard shipping cost: ${standardCost}");

calculator.SetStrategy(expressShipping);
decimal expressCost = calculator.CalculateShipping(order);
Console.WriteLine($"Express shipping cost: ${expressCost}");

calculator.SetStrategy(nextDayShipping);
decimal nextDayCost = calculator.CalculateShipping(order);
Console.WriteLine($"Next day shipping cost: ${nextDayCost}");

// we can also create a factory to get the appropriate strategy:
public static IShippingStrategy GetShippingStrategy(string method)
{
    return method switch
    {
        "Standard" => new StandardShippingStrategy(),
        "Express" => new ExpressShippingStrategy(),
        "NextDay" => new NextDayShippingStrategy(),
        _ => throw new ArgumentException("Unsupported shipping method")
    };
}

// And use it like this:
calculator.SetStrategy(GetShippingStrategy("Express"));

Advantages

Open/Closed Principle: You can add new strategies without modifying existing code
Single Responsibility Principle: Each strategy encapsulates its own algorithm
Improved Testability: Strategies can be tested independently
Runtime Flexibility: Algorithms can be switched during runtime
Elimination of Conditional Logic: Reduces or eliminates complex if/else or switch statements
Code Reuse: Strategies can be reused across different contexts
Maintainability: Easier to understand and maintain multiple simple classes than one complex class

Disadvantages and Limitations

Increased Number of Classes: Creates more classes, which can add complexity
Client Must Be Aware of Strategies: The client must know which strategy to select
Communication Overhead: Strategies might need data from the context, requiring parameter passing
Overkill for Simple Cases: May be unnecessary for applications with only one or two simple algorithms
Memory Usage: Additional objects are created, which might impact performance in memory-constrained environments

Related Patterns

Factory Method: Often used with Strategy to instantiate the appropriate strategy

Best Practices and Tips

Use dependency injection to provide strategies to the context
Consider using a factory method to create strategies
Keep the strategy interface focused and cohesive
Ensure strategies have access to all the data they need to function
Use default strategies when appropriate
Document the behavior of each strategy clearly
Consider making strategies stateless to improve reusability

Conclusion

The Strategy Design Pattern is a powerful tool for managing algorithms, behaviors, or processes that need to vary independently from clients that use them. By encapsulating different algorithms in separate classes with a common interface, it promotes code that is more maintainable, extensible, and adheres to SOLID principles.

When you find yourself writing complex conditional logic to choose between different algorithms or behaviors, consider the Strategy pattern. It's particularly valuable in systems that need to support multiple ways of performing the same task, especially when those algorithms need to be selected at runtime or are likely to change over time.
