Creating your own bindings is a way to connect different programming languages, allowing you to use the capabilities of one language in another. For example, you can connect the functionality of a Go application to Lua scripts. Today, I'll show you how to write your own bindings in two different ways.

Preparation

Let's assume you have a program that performs specific logic and has an interface. Suppose it calculates the SHA-256 hash of query parameters according to a given logic:

 //lib.go
 func sha256Raw(input string) string {
    // Parse the input URL
    urlParsed, err := url.Parse(input)
    if err != nil {
        return ""
    }
    // Hash the raw query string
    hash := sha256.New()
    hash.Write([]byte(urlParsed.RawQuery))
    return hex.EncodeToString(hash.Sum(nil))
}

Here's a simple main function to demonstrate its usage:

//main.go
package main

import (
    "flag"
)

var (
    algorithmFlag = flag.String("algorithm", "", "The hashing algorithm to use")
    inputFlag     = flag.String("input", "", "The input to hash")
)

func init() {
    flag.Parse()
}

func main() {
    switch *algorithmFlag {
    case "sha256_raw":
        hash := sha256Raw(*inputFlag)
        println(hash)
    default:
        println("Unknown algorithm")
    }
}

Build and install the program in /usr/local/bin/ so it's available system-wide:

$ go build -o hasher .
$ cp hasher /usr/local/bin/hasher

Now we have a hasher binary that can be used like this:

$ hasher -algorithm sha256_raw -input 'https://example.com/some/link?q1=1&q2=2&g=3'
ca2a598def71c556327b531e2be48fbba879e2d596acdb60006b6ff4626dec2d

Moving on to Lua

Let's explore the simplest binding: a wrapper around a CLI command and its arguments.
Our interface is hasher, which requires two mandatory flag parameters: algorithm and input. It returns the resulting string. From here on, I'll use test.lua as one of the usage examples:

-- test.lua
local hasherbinding = require("hasherbinding")
print(hasherbinding.hash("sha256_raw", "https://example.com/some/link?q1=1&q2=2&g=3")) -- Should print ca2a598def71c556327b531e2be48fbba879e2d596acdb60006b6ff4626dec2d`

Let's start by creating the simplest Lua module, hasherbinder:

-- hasherbinder.lua
local hasherbinder = {}

function hasherbinder.hash(alg, input)
     return "result"
end

return hasherbinder

At this stage, it only returns the string "result". Next, we'll add a call to io.popen with the command string and parameters, and read the response. Ultimately, our hasherbinder.lua will look something like this:

-- hasherbinder.lua
local hasherbinder = {}

local hasherformat = "hasher -algorithm %s -input '%s'"

function hasherbinder.hash(alg, input)
    local handle = io.popen(string.format(hasherformat, alg, input))
    local result = handle:read("*a")
    handle:close()
    return result
end

return hasherbinder

Run test.lua and check the result:

$ lua test.lua
ca2a598def71c556327b531e2be48fbba879e2d596acdb60006b6ff4626dec2d

We successfully executed Go code from Lua using the compiled binary.
But... that's not enough for us, right?

Let's Go Down the Rabbit Hole

Suppose we don't want to use the CLI to call the entire binary but want to call specific methods directly, and we have access to the source code. To solve this problem, we can build a C-Shared-Library using cgo.

Small disclaimer: Everything that follows was done on macOS with Lua version 5.4.7. Paths to libraries and headers might differ on other operating systems and versions. I'll omit the details on how to install gcc and where to find Lua headers and libraries.

Let's continue...
Suppose our Go code has another method we want to expose:

//lib.go
func doubleMd5Sorted(input string) string {
    // Parse the input URL
    urlParsed, err := url.Parse(input)
    if err != nil {
        return ""
    }
    // Sort the query parameters
    queryParams := urlParsed.Query()
    keys := make([]string, 0, len(queryParams))
    for key := range queryParams {
        keys = append(keys, key)
    }
    sort.Strings(keys)
    // Create the sorted query string
    sortedParams := []string{}
    for _, key := range keys {
        sortedParams = append(sortedParams, key+"="+queryParams.Get(key))
    }
    sortedParamsStr := strings.Join(sortedParams, "&")
    // Hash the sorted query string twice
    firstHash := md5.Sum([]byte(sortedParamsStr))
    secondHash := md5.Sum(firstHash[:])
    return hex.EncodeToString(secondHash[:])
}

Let's modify our test.lua to call both methods:

-- test.lua
local hasherbinding = require("hasherbinding")
print(hasherbinding.sha256_raw("https://example.com/some/link?q1=1&q2=2&g=3")) -- Should print ca2a598def71c556327b531e2be48fbba879e2d596acdb60006b6ff4626dec2d
print(hasherbinding.double_md5_sorted("https://example.com/some/link?q1=1&q2=2&g=3")) -- Should print 72df8c4cc5ae9c072fc101de65124298

So, to make this work, we need to add a cgo.go file to our project and define the exported functions in it like this:

//cgo.go
package main

import "C"

//export DoubleMd5Sorted
func DoubleMd5Sorted(input *C.char) *C.char {
    goInput := C.GoString(input)
    result := doubleMd5Sorted(goInput)
    return C.CString(result)
}

//export Sha256Raw
func Sha256Raw(input *C.char) *C.char {
    goInput := C.GoString(input)
    result := sha256Raw(goInput)
    return C.CString(result)
}

Note: In these methods, we convert C strings (*C.char) to Go strings and back. Ideally, the memory allocated for C.CString should be freed manually using C.free, but since the result will be used elsewhere here, we'll free it there.

Lets build a C Shared Library from the project:

go build -o lib/libhasher.so -buildmode=c-shared .

In the output lib folder, we now have two files: libhasher.h and libhasher.so.
We'll need these to write the Lua binder in C.
Install libhasher.so into /usr/local/lib/:

sudo cp lib/libhasher.so /usr/local/lib/libhasher.so

To ensure the OS knows where the libraries are, don't forget to add the /usr/local/lib directory to DYLD_LIBRARY_PATH or LD_LIBRARY_PATH if it's not already there. This will save us from having to specify full paths to custom libraries in the future.

$ export DYLD_LIBRARY_PATH=/usr/local/lib:$DYLD_LIBRARY_PATH
$ export LD_LIBRARY_PATH=/usr/local/lib:$LD_LIBRARY_PATH

Let's write the binder itself

Create a src/ directory and place our header file libhasher.h there. Next to it, create hasherbinding.c where we describe our Lua module in C:

#include
#include
#include "libhasher.h"

int lua_sha256_raw(lua_State *L) {
    const char* str = luaL_checkstring(L, 1);
    char* result = Sha256Raw((char*)str);
    lua_pushstring(L, result);
    free(result); // Free the C string allocated by C.CString
    return 1;
}

int lua_double_md5_sorted(lua_State *L) {
    const char* str = luaL_checkstring(L, 1);
    char* result = DoubleMd5Sorted((char*)str);
    lua_pushstring(L, result);
    free(result); // Free the C string allocated by C.CString
    return 1;
}

// Register your functions
int luaopen_hasherbinding(lua_State *L) {
    static const struct luaL_Reg mylib[] = {
        {"sha256_raw", lua_sha256_raw},
        {"double_md5_sorted", lua_double_md5_sorted},
        {NULL, NULL}
    };
    luaL_newlib(L, mylib);
    return 1;
}

The main magic happens in the luaopen_hasherbinding function: when the Lua interpreter tries to load a module via require("mymodule"), it looks for shared libraries and tries to find the function luaopen_ to initialize the module. In our case, using the Lua C API and lua_State *L, we initialize the two functions of our module, which handle the core logic.

Let's build our binder and check the result:

gcc -shared -o hasherbinding.so \
    -fPIC src/hasherbinding.c \
    -I/opt/homebrew/Cellar/lua/5.4.7/include/lua5.4 \
    -L/opt/homebrew/Cellar/lua/5.4.7/lib \
    -llua -lhasher

What's happening here:

src/hasherbinding.c and -o hasherbinding.so specify which file to compile and where to put the result.
-shared and -fPIC tell the compiler to create a shared library and that we need Position-Independent Code (necessary for shared libraries), meaning code that can be loaded into memory without modification.
-I/opt/homebrew/Cellar/lua/5.4.7/include/lua5.4 tells the compiler where to find the header files lua.h and lauxlib.h for the #include directives.
-L/opt/homebrew/Cellar/lua/5.4.7/lib tells the compiler where to find the libraries defined in the header files.
-llua and -lhasher specify which libraries to link. Since we added /usr/local/lib to LD_LIBRARY_PATH, hasher will be found there. Let's check the result Look at test.lua again:

-- test.lua
local hasher = require("hasherbinding")
print(hasher.sha256_raw("https://example.com/some/link?q1=1&q2=2&g=3")) -- Should print ca2a598def71c556327b531e2be48fbba879e2d596acdb60006b6ff4626dec2d
print(hasher.double_md5_sorted("https://example.com/some/link?q1=1&q2=2&g=3")) -- Should print 72df8c4cc5ae9c072fc101de65124298

and run it:

lua test.lua
ca2a598def71c556327b531e2be48fbba879e2d596acdb60006b6ff4626dec2d
72df8c4cc5ae9c072fc101de65124298

Conclusion

Writing bindings opens up many new possibilities, from integrating languages to extending application functionality. Today, we successfully wrote a simple Lua binder for a program written in Go.
