Understanding Pods, Deployments, and Services in Kubernetes

Kubernetes can feel like a complex ecosystem, but once you understand its building blocks, everything starts to make sense. In this article, we’ll explore the three most fundamental components in Kubernetes: Pods, Deployments, and Services.

By the end, you’ll have a solid understanding of how your applications are deployed, managed, and exposed in a Kubernetes cluster.

What is a Pod?

A Pod is the smallest and most basic deployable unit in Kubernetes. A Pod represents a single instance of a running process in your cluster.

Key Characteristics:

A Pod can contain one or more containers (usually one).
Containers in a Pod share:
- The same network namespace (same IP address and port space).
- The same storage volumes, if defined.

Think of a Pod as a wrapper around one or more tightly coupled containers that must run together.

Why Pods?

Pods are useful for:

Running a containerized app.
Grouping helper containers (like logging agents) with the main container.

Examples -

Simple Pod:

apiVersion: v1
kind: Pod
metadata:
  name: nginx
spec:
  containers:
  - name: nginx-container
    image: nginx:latest
    ports:
    - containerPort: 80

Pod with Volumes, Multiple Containers including init containers and environment variables:

apiVersion: v1
kind: Pod
metadata:
  name: myapp-pod
  labels:
    app.kubernetes.io/name: MyApp
spec:
  containers:
    - name: myapp-container
      image: busybox:1.28
      command: ['sh', '-c', 'echo The app is running! && sleep 3600']
      env:
        - name: ENVIRONMENT
          value: "production"
        - name: CONFIG_FILE
          value: "/etc/config/app.conf"
      volumeMounts:
        - name: config-vol
          mountPath: /etc/config
  initContainers:
    - name: init-myservice
      image: busybox:1.28
      command: ['sh', '-c', "until nslookup myservice.$(cat /var/run/secrets/kubernetes.io/serviceaccount/namespace).svc.cluster.local; do echo waiting for myservice; sleep 2; done"]
    - name: init-mydb
      image: busybox:1.28
      command: ['sh', '-c', "until nslookup mydb.$(cat /var/run/secrets/kubernetes.io/serviceaccount/namespace).svc.cluster.local; do echo waiting for mydb; sleep 2; done"]
  volumes:
    - name: config-vol
      configMap:
        name: log-config
        items:
          - key: log_level
            path: log_level.conf

Manifest breakup for better understanding

Here are breakdowns for the components used in the above manifest:

Environment Variables

   env:
     - name: DEMO_GREETING
       value: "Hello from the environment"
     - name: DEMO_FAREWELL
       value: "Such a sweet sorrow"

Volumes

Volumes are defined in the volumes section of the manifest. They can be used/mounted by one or more containers in the Pod.

    volumeMounts:
      - name: config-vol
        mountPath: /etc/config
  volumes:
    - name: config-vol
      configMap:
        name: log-config
        items:
          - key: log_level
            path: log_level.conf

Init Containers

Init containers are used to perform setup tasks before the main containers in the Pod start.

  initContainers:
    - name: init-myservice
      image: busybox:1.28
      command: ['sh', '-c', "until nslookup myservice.$(cat /var/run/secrets/kubernetes.io/serviceaccount/namespace).svc.cluster.local; do echo waiting for myservice; sleep 2; done"]
    - name: init-mydb
      image: busybox:1.28
      command: ['sh', '-c', "until nslookup mydb.$(cat /var/run/secrets/kubernetes.io/serviceaccount/namespace).svc.cluster.local; do echo waiting for mydb; sleep 2; done"]

What is a Deployment?

While a Pod is great, it’s not self-healing. If a Pod crashes, it won’t come back automatically. That’s where a Deployment comes in.

A Deployment is a higher-level abstraction that manages Pods and ReplicaSets for you.

Key Benefits:

Ensures desired state is maintained (e.g., always 3 replicas running).
Supports rolling updates and rollbacks.
Automatically replaces failed Pods.

Examples:

Simple Deployment:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: nginx:1.25
        ports:
        - containerPort: 80

Note: Most of the fields in the Deployment manifest are the same as in a Pod manifest. The key difference is that in a Deployment, you specify the number of replicas you want to run. It is specified in the replicas field.

Deployment with Volumes, Multiple Containers including init containers and environment variables:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: demo-app
  labels:
    app: demo
spec:
  replicas: 2
  selector:
    matchLabels:
      app: demo
  template:
    metadata:
      labels:
        app: demo
    spec:
      volumes:
        - name: shared-data
          emptyDir: {}
        - name: config-volume
          configMap:
            name: demo-config
      initContainers:
        - name: init-myservice
          image: busybox
          command: ['sh', '-c', 'echo "Initializing..." > /mnt/data/init.log']
          volumeMounts:
            - name: shared-data
              mountPath: /mnt/data
      containers:
        - name: demo-container
          image: nginx:1.25
          ports:
            - containerPort: 80
          env:
            - name: ENVIRONMENT
              value: "production"
            - name: CONFIG_FILE
              value: "/etc/config/app.conf"
          volumeMounts:
            - name: shared-data
              mountPath: /usr/share/nginx/html/init
            - name: config-volume
              mountPath: /etc/config
              readOnly: true
---
#configmap-manifest
apiVersion: v1
kind: ConfigMap
metadata:
  name: demo-config
data:
  app.conf: |
    server {
      listen 80;
      location / {
        return 200 "Hello from ConfigMap!";
      }
    }

Some more manifest breakups for better understanding

Shared Volumes

Same volumes can be shared by multiple containers in a Pod. This is useful for sharing data between containers in the same Pod.
      volumes:
        - name: shared-data
          emptyDir: {}
      initContainers:
        - volumeMounts:
            - name: shared-data
              mountPath: /mnt/data
      containers:
        - volumeMounts:
            - name: shared-data
              mountPath: /usr/share/nginx/html/init
Configmap as volumes

ConfigMaps can be used in two primary ways:

As environment variables

As volumes (mounted files inside your container) In this example, we've mounted it as a volume - for configmap manifest, refer to the #configmap-manifest section in the above manifest.
      volumes:
        - name: config-volume
          configMap:
            name: demo-config
      containers:
        - volumeMounts:
            - name: config-volume
              mountPath: /etc/config
              readOnly: true
Once deployed, inside the container you’ll have:
/etc/config/app.conf
This config file is then used by the container to configure the application using environment variable.
      containers:
        - env:
            - name: CONFIG_FILE
              value: "/etc/config/app.conf"
Note: Mounting ConfigMap as a volume makes the config read-only by default, which is a nice security feature.

What is a Service?

A Service in Kubernetes exposes your Pods to other applications inside (or outside) the cluster.

Types of Services:

ClusterIP (default): Internal communication only.
NodePort: Exposes the service on a port on each node.
LoadBalancer: Exposes the service externally using a cloud provider's load balancer.
ExternalName: Maps the service to an external DNS name.

Example (NodePort):

apiVersion: v1
kind: Service
metadata:
  name: nginx-service
spec:
  type: NodePort
  selector:
    app: nginx
  ports:
  - port: 80
    targetPort: 80
    nodePort: 30007

This will expose your nginx deployment on http://:30007.

Putting it All Together: A Practical Example

Here’s an example to deploy Nginx and expose it via a NodePort service.
