Building an Artificial Neural Network to make Predictions with Machine Learning.

Introduction

Artificial Neural Networks (ANNs) are computational models inspired by the human brain's biological neural networks. They are designed to simulate the way humans learn and process information. By recognizing patterns, approximating functions, and optimizing tasks, ANNs serve as the backbone of many artificial intelligence (AI) applications.

Biological Inspiration

In the human brain, neurons are the fundamental units that transmit signals. Each neuron receives input, processes it, and passes the result to other neurons. ANNs replicate this behavior by using nodes (artificial neurons) organized in layers:

Input Layer: Takes in raw data.
Hidden Layers: Perform intermediate computations.
Output Layer: Produces the final result.

Each connection between neurons has an associated weight which is adjusted during training.

Structure of an ANN

An ANN typically consists of:

Neurons: Basic processing units.
Layers: Organized into input, hidden, and output.
Weights and Biases: Parameters adjusted during training.
Activation Function: Determines the output of a neuron.

Common activation functions:

Sigmoid: ( \sigma(x) = \frac{1}{1 + e^{-x}} )
ReLU (Rectified Linear Unit): ( f(x) = \max(0, x) )
Tanh: ( \tanh(x) = \frac{e^x - e^{-x}}{e^x + e^{-x}} )

Training an ANN

Training involves adjusting the weights and biases to minimize error using a method called Backpropagation. The key steps are:

Forward Propagation: Calculate outputs based on current weights.
Loss Calculation: Compute the error (e.g., Mean Squared Error).
Backpropagation: Adjust weights using gradients.
Optimization: Apply an algorithm like Stochastic Gradient Descent (SGD) or Adam to update weights.

Python Implementation of a Simple ANN (From Scratch)

import numpy as np

def sigmoid(x):
    return 1 / (1 + np.exp(-x))

def sigmoid_derivative(x):
    return x * (1 - x)

# Input data (4 samples, 2 features)
x = np.array([[0, 0],
              [0, 1],
              [1, 0],
              [1, 1]])

# Output data (4 samples, 1 output)
y = np.array([[0],
              [1],
              [1],
              [0]])  # XOR problem

# Seed random numbers for reproducibility
np.random.seed(1)

# Initialize weights randomly with mean 0
input_layer_neurons = 2
hidden_layer_neurons = 4
output_neurons = 1

weights_input_hidden = 2 * np.random.random((input_layer_neurons, hidden_layer_neurons)) - 1
weights_hidden_output = 2 * np.random.random((hidden_layer_neurons, output_neurons)) - 1

# Training process
epochs = 10000
learning_rate = 0.1

for epoch in range(epochs):
    # Forward propagation
    hidden_input = np.dot(x, weights_input_hidden)
    hidden_output = sigmoid(hidden_input)

    final_input = np.dot(hidden_output, weights_hidden_output)
    predicted_output = sigmoid(final_input)

    # Backpropagation
    error = y - predicted_output
    d_predicted_output = error * sigmoid_derivative(predicted_output)

    error_hidden_layer = d_predicted_output.dot(weights_hidden_output.T)
    d_hidden_layer = error_hidden_layer * sigmoid_derivative(hidden_output)

    # Updating Weights
    weights_hidden_output += hidden_output.T.dot(d_predicted_output) * learning_rate
    weights_input_hidden += x.T.dot(d_hidden_layer) * learning_rate

    if epoch % 1000 == 0:
        loss = np.mean(np.square(error))
        print(f"Epoch {epoch} Loss: {loss:.4f}")

# Final output
print("\nFinal Predicted Output:")
print(predicted_output)

Applications of ANN

Computer Vision: Image classification, object detection
Natural Language Processing (NLP): Language translation, sentiment analysis
Healthcare: Disease prediction, medical image analysis
Finance: Fraud detection, algorithmic trading
Robotics: Autonomous navigation, control systems

Summary

Artificial Neural Networks are powerful tools capable of learning from data and making complex decisions. They consist of layers of interconnected neurons that adapt through training. As data-driven models, their effectiveness continues to grow with more data, better algorithms, and advanced hardware.
