A comprehensive how to on Tab layout for android

//activity_main.xml Pager android:id="@+id/view_pager" android:layout_width="match_parent" android:layout_height="match_parent" /> //MainActivity.java public class MainActivity extends AppCompatActivity { private TabLayout tabLayout; private ViewPager viewPager; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); tabLayout = findViewById(R.id.tab_layout); viewPager = findViewById(R.id.view_pager); tabLayout.addTab(tabLayout.newTab().setText("Purchase Tickets")); tabLayout.addTab(tabLayout.newTab().setText("Profile")); tabLayout.addTab(tabLayout.newTab().setText("Past Bookings")); final PagerAdapter adapter = new PagerAdapter(getSupportFragmentManager(), tabLayout.getTabCount()); viewPager.setAdapter(adapter); viewPager.addOnPageChangeListener(new TabLayout.TabLayoutOnPageChangeListener(tabLayout)); tabLayout.addOnTabSelectedListener(new TabLayout.OnTabSelectedListener() { @Override public void onTabSelected(TabLayout.Tab tab) { viewPager.setCurrentItem(tab.getPosition()); } @Override public void onTabUnselected(TabLayout.Tab tab) {} @Override public void onTabReselected(TabLayout.Tab tab) {} }); } } //PagerAdapter.java public class PagerAdapter extends FragmentPagerAdapter { private int numOfTabs; public PagerAdapter(FragmentManager fm, int numOfTabs) { super(fm); this.numOfTabs = numOfTabs; } @Override public Fragment getItem(int position) { (position) { case 0: return new PurchaseTicketsFragment(); case 1: return new ProfileFragment(); case 2: return new PastBookingsFragment(); default: return null; } } @Override public int getCount() { return numOfTabs; } } //fragment_purchase_tickets.xml //PurchaseTicketsFragment.java public class PurchaseTicketsFragment extends Fragment { private EditText nameEditText, ageEditText; private DatePicker datePicker; private TimePicker timePicker; private Spinner seatTypeSpinner; private Button submitButton; @Override public View onCreateView(LayoutInflater inflater, ViewGroup container, Bundle savedInstanceState) { View view = inflater.inflate(R.layout.fragment_purchase_tickets, container, false); nameEditText = view.findViewById(R.id.name); ageEditText = view.findViewById(R.id.age); datePicker = view.findViewById(R.id.date_picker); timePicker = view.findViewById(R.id.time_picker); seatTypeSpinner = view.findViewById(R.id.seat_type_spinner); submitButton = view.findViewById(R.id.submit_button); submitButton.setOnClickListener(v -> submitTicket()); return view; } private void submitTicket() { String name = nameEditText.getText().toString(); String age = ageEditText.getText().toString(); String date = datePicker.getDayOfMonth() + "/" + (datePicker.getMonth() + 1) + "/" + datePicker.getYear(); String time = timePicker.getHour() + ":" + timePicker.getMinute(); String seatType = seatTypeSpinner.getSelectedItem().toString(); // Handle ticket submission logic here // Navigate to ticket printing activity Intent intent = new Intent(getActivity(), TicketPrintingActivity.class); intent.putExtra("name", name); intent.putExtra("age", age); intent.putExtra("date", date); intent.putExtra("time", time); intent.putExtra("seatType", seatType); startActivity(intent); } } //activity_login_signup.xml //LoginSignupActivity.java

Apr 16, 2025 - 08:50

A comprehensive how to on Tab layout for android

//activity_main.xml







   Pager
        android:id="@+id/view_pager"
        android:layout_width="match_parent"
        android:layout_height="match_parent" />

//MainActivity.java
public class MainActivity extends AppCompatActivity {

    private TabLayout tabLayout;
    private ViewPager viewPager;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        tabLayout = findViewById(R.id.tab_layout);
        viewPager = findViewById(R.id.view_pager);

        tabLayout.addTab(tabLayout.newTab().setText("Purchase Tickets"));
        tabLayout.addTab(tabLayout.newTab().setText("Profile"));
        tabLayout.addTab(tabLayout.newTab().setText("Past Bookings"));

        final PagerAdapter adapter = new PagerAdapter(getSupportFragmentManager(), tabLayout.getTabCount());
        viewPager.setAdapter(adapter);
        viewPager.addOnPageChangeListener(new TabLayout.TabLayoutOnPageChangeListener(tabLayout));

        tabLayout.addOnTabSelectedListener(new TabLayout.OnTabSelectedListener() {
            @Override
            public void onTabSelected(TabLayout.Tab tab) {
                viewPager.setCurrentItem(tab.getPosition());
            }

            @Override
            public void onTabUnselected(TabLayout.Tab tab) {}

            @Override
            public void onTabReselected(TabLayout.Tab tab) {}
        });
    }
}

//PagerAdapter.java
public class PagerAdapter extends FragmentPagerAdapter {

    private int numOfTabs;

    public PagerAdapter(FragmentManager fm, int numOfTabs) {
        super(fm);
        this.numOfTabs = numOfTabs;
    }

    @Override
    public Fragment getItem(int position) {
        (position) {
            case 0:
                return new PurchaseTicketsFragment();
            case 1:
                return new ProfileFragment();
            case 2:
                return new PastBookingsFragment();
            default:
                return null;
        }
    }

    @Override
    public int getCount() {
        return numOfTabs;
    }
}

//fragment_purchase_tickets.xml

//PurchaseTicketsFragment.java
public class PurchaseTicketsFragment extends Fragment {

    private EditText nameEditText, ageEditText;
    private DatePicker datePicker;
    private TimePicker timePicker;
    private Spinner seatTypeSpinner;
    private Button submitButton;

    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container, Bundle savedInstanceState) {
        View view = inflater.inflate(R.layout.fragment_purchase_tickets, container, false);

        nameEditText = view.findViewById(R.id.name);
        ageEditText = view.findViewById(R.id.age);
        datePicker = view.findViewById(R.id.date_picker);
        timePicker = view.findViewById(R.id.time_picker);
        seatTypeSpinner = view.findViewById(R.id.seat_type_spinner);
        submitButton = view.findViewById(R.id.submit_button);

        submitButton.setOnClickListener(v -> submitTicket());

        return view;
    }

    private void submitTicket() {
        String name = nameEditText.getText().toString();
        String age = ageEditText.getText().toString();
        String date = datePicker.getDayOfMonth() + "/" + (datePicker.getMonth() + 1) + "/" + datePicker.getYear();
        String time = timePicker.getHour() + ":" + timePicker.getMinute();
        String seatType = seatTypeSpinner.getSelectedItem().toString();

        // Handle ticket submission logic here
        // Navigate to ticket printing activity
        Intent intent = new Intent(getActivity(), TicketPrintingActivity.class);
        intent.putExtra("name", name);
        intent.putExtra("age", age);
        intent.putExtra("date", date);
        intent.putExtra("time", time);
        intent.putExtra("seatType", seatType);
        startActivity(intent);
    }
}

//activity_login_signup.xml
//LoginSignupActivity.java
